Inspur NF8260M5 Server Overview

Check Inspur All Servers

View the overview of Inspur rack servers, tower servers and more products, and select the best one for your business.

• Inspur Rack Servers • Inspur Tower Servers • All Servers

Learn Details

Inspur NF8260M5 Server is a high-density, widely flexible, and powerful four socket 2U server which adapts to any demanding enterprise workload with ultra-dense memory design to enhance space efficiency. OCP Accepted NF8260M5 Open Platform, contributed by Inspur and Intel.

Quick Spec

Table 1 shows the quick spec.

Model	NF8260M5
Form Factor	2U rack-mount, 780mm (D)
Processor	Intel® Xeon® Scalable, two-socket/four-socket, support max. 28 cores
Chipset	Intel ® C620 series chipset
Memory	12 DIMM slots per processor, 6 channels per processor, 2 DIMM per channel RDIMM, LRDIMM and NVDIMM Max. Capacity (RDIMM): 1.5TB, 48x 32GB @2666 MHz Max. Capacity (LRDIMM): 6.0TB, 48x 128GB @2666 MHz
PCI Slots	Up to 8x standard PCI-E slots and support one optional OCP Mezz

Product Details

Inspur NF8260M5 Server provides these features:

· OCP Accepted™

Jointly contributed by Inspur and Intel

· Scalable 4P Performance in a Dense 2U Form Factor.

Designed for the enterprise, all the power and capacity required to meet business needs.

· Reliability for Multiple Workloads.

Support for up to two 2000W Power Supplies for increasing redundancy and reducing unnecessary downtime.

· Flexible Expandability.

Support up to eight PCI-E expansion cards, including graphic processor units and network adapters, offering increased expandability.

Compare to Similar Item

Table 2 shows the comparison.

Model	NF8260M5	NF5266M5
Specifications	2U rack-mount, 780mm (D)	2U Rackmount Server
Processor	Intel® Xeon® Scalable, two-socket/four-socket, support max. 28 cores	Up to 2x Intel® Xeon® Processor Scalable Family Maximum TDP: 165W Interconnection: 2x UPI interconnection links, up to 10.4GT/s per link
Chipset	Intel ® C620 series chipset	Intel LBG-2 (C622)
Memory	12 DIMM slots per processor, 6 channels per processor, 2 DIMM per channel RDIMM, LRDIMM and NVDIMM Max. Capacity (RDIMM): 1.5TB, 48x 32GB @2666 MHz Max. Capacity (LRDIMM): 6.0TB, 48x 128GB @2666 MHz	Slots: Up to 12x DDR4 DIMM slots Type: Support RDIMM /LRDIMM, speed up to 2933MT/s Maximum Capacity: Up to 768GB (64G*12 RDIMM/LRDIMM)

Get More Information

Do you have any question about the NF8260M5?

Inspur NF8260M5 Server Specification

Inspur NF8260M5 Server Specification
Form Factor	2U rack-mount, 780mm (D)
Processor	Intel® Xeon® Scalable, two-socket/four-socket, support max. 28 cores
Chipset	Intel ® C620 series chipset
Memory	12 DIMM slots per processor, 6 channels per processor, 2 DIMM per channel RDIMM, LRDIMM and NVDIMM Max. Capacity (RDIMM): 1.5TB, 48x 32GB @2666 MHz Max. Capacity (LRDIMM): 6.0TB, 48x 128GB @2666 MHz
PCI Slots	Up to 8x standard PCI-E slots and support one optional OCP Mezz
Internal Storage	Up to 24x 2.5” SAS/SATA or 6x NVMe SSD
Ethernet	Integrated LAN controller; up to 4x 10GbE
Power Supply	800W/1300W/1600W/2000W, support 1+1 redundancy
M.2 & SD support	Up to two M.2
